Sanwa PC7000 Digital Multimeter with True RMS and PC Link

₱15,628.00

Category: Sanwa Tags: Digital Multimeter, SANWA

PC7000	Measuring range	Best accuracy	Resolution	Input impedance
DCV	500m/5/50/500/600V	±(0.03%+2)	0.01mV	10MΩ
ACV	500m/5/50/500/600V	±(0.5%+40)	0.01mV	10MΩ
DCA	500μ/5000μ/50m/500m/5/10A	±(0.1%+20)	0.01μA
ACA	500μ/5000μ/50m/500m/5/10A	±(0.6%+40)	0.01μA
Resistance	500/5k/50k/500k/5M/50MΩ	±(0.2%+6)	0.01Ω
Conductance	99.99nS	±(1.0%+10)	0.01nS
Capacitance	50n/500n/5μ/50μ/500μ/5m/25mF	±(0.8%+3）※	0.01nF
Temperature	-50～1000°C(thermocouple K type)	±(0.3%+20)	0.1°C
Frequency	10Hz～200kHz	±(0.02%+40)	0.001Hz
Logic frequency	5Hz～2MHz	±(0.002%+4)	0.001Hz
Duty cycle	0.1%～99.99%	±(3d/kHz+2)	0.01%
dBm	-29.83dBm～54.25dBm	±(0.25dB+2)	0.01dB
4-20mA%	4mA=0% 20mA=100%	±25d	0.01%
Continuity	Buzzer sounds at between 20Ω and 200Ω Open voltage:approx.1.3
Diode test	Open voltage:approx.3V

Display	numeral display 50000 & 500000 selectable, bar graph 41 segments
Sampling rate	5 times/sec. for 50000 count, 1.25 times/sec.for 500000 count, 60 times/sec.for bar graph
Bandwidth	V:45Hz～1kHz,1kHz～20kHz（below 500V） A:40Hz～1kHz
Fuse	11A/1000V IR20kA Φ10× 38 mm 0.4A/1000V IR30kA Φ 6.3× 32 mm
Battery	6LR61(9V)x1
Battery life	Approx.100h (alkaline battery) at DCV range
Size/Mass	H184×W86×D52mm/approx.430g（Including Holster)
Safety	IEC61010 CAT.Ⅲ600V

Description

50000 & 500000 counts
(Selectable 5-4 / 5 digits 500000 counts for DCV)
Dual display shows voltage/current and its frequency, and AC components and DC components of voltage/current
Low-pass filter for variable frequency drive(VFD) circuit
Capture (peak hold), Interval: 0.8ms
MAX/MIN/AVG recording mode
K type thermocouple temperature measurement -50℃ ～ 1000℃
Conductance measurement
Auto power save (17min.)(cancelable)
